1. Dengan motor magnet permanen efisiensi tinggi, efisiensi meningkat sebesar 15% -30%.
2, perlindungan lingkungan, energi bersih, dapat didukung oleh panel surya dan baterai.
3. Over-load protection, under-load protection, lock-rotor protection, thermal protection.
4. Dengan fungsi MPPT.
5. Hidup lebih lama dari pompa Air AC normal.
Banyak digunakan dalam irigasi pertanian, air minum dan penyediaan air hidup
| MODEL | Voltase | Tegangan DC Terbaik | Kekuasaan | Maks.Mengalir | Maks.Kepala | Toko | Kabel | Panel surya | |
| tegangan terbuka | Kekuasaan | ||||||||
| V | V | W | m3/jam | M | inci | M | V | w | |
| 3DSC3-27-24-200 | 24 | 15-48 | 200 | 3 | 27 | r | 2 | <50 | 300 |
| 3DSC3-33-24-300 | 24 | 15-48 | 300 | 3 | 33 | r | 2 | <50 | 450 |
| 3DSC3-70-48-600 | 48 | 36-90 | 600 | 3 | 70 | r | 2 | <100 | 900 |
| 3DSC3-70-72-600 | 72 | 55-120 | 600 | 3 | 70 | r | 2 | <150 | 900 |
| 3DSC3-90-48-750 | 48 | 36-90 | 750 | 3 | 90 | r | 2 | <100 | 1100 |
| 3DSC3-90-72-750 | 72 | 55-120 | 750 | 3 | 90 | r | 2 | <150 | 1100 |
| 3DSC3-138-72-1100 | 72 | 55-120 | 1100 | 3 | 138 | r | 2 | <150 | 1600 |
| 3DSC3-138-110-1100 | 110 | 80-150 | 1100 | 3 | 138 | r | 2 | <220 | 1600 |
| 3DSC3-178-110-1500 | 110 | 80-150 | 1500 | 3 | 178 | r | 2 | <220 | 2200 |
| 3DSC4-45-48-600 | 48 | 36-90 | 600 | 4 | 45 | 1,25" | 2 | <100 | 2900 |
| 3DSC4-45-72-600 | 72 | 55-120 | 600 | 4 | 45 | 1,25" | 2 | <150 | 900 |
| 3DSC4-67-48-750 | 48 | 36-90 | 750 | 4 | 67 | 1,25" | 2 | <100 | 1100 |
| 3DSC4-67-72-750 | 72 | 55-120 | 750 | 4 | 67 | 1.25n | 2 | <150 | 1100 |
| 3DSC4.5-96-72-1100 | 72 | 55-120 | 1100 | 4.5 | 96 | 1.25n | 2 | <150 | 1600 |
| 3DSC4.5-96-110-1100 | 110 | 80-150 | 1100 | 4.5 | 96 | 1,25" | 2 | <220 | 1600 |
| 3DSC4.5-124-110-1500 | 110 | 80-150 | 1500 | 4.5 | 124 | 1.25n | 2 | <220 | 2200 |
| 3DSC5.5-51-72-750 | 72 | 55-120 | 750 | 5.5 | 51 | 1,25" | 2 | <150 | 1100 |
| 3DSC6-73-72-1100 | 72 | 55-120 | 1100 | 6 | 73 | 1,25" | 2 | <150 | 1600 |
| 3DSC6-73-110-1100 | 110 | 80-150 | 1100 | 6 | 73 | 1,25" | 2 | <220 | 1600 |
| 3DSC6.5-93-110-1500 | 110 | 80-150 | 1500 | 6.5 | 93 | 1,25" | 2 | <220 | 2200 |
